Product Description
Fuel Pump Module Assembly
Fitment
Ford Expedition
2003-04 - V8 5.4L
Product Attributes
Inlet Quantity: 0
Outlet Quantity: 1
Resistance Ohms Empty: 16 Ohms
Resistance Ohms Full: 160 Ohms
Minimum Flow Rating: 38 gph
Average Flow Rating: 42 gph
Maximum Flow Rating: 46.23 gph
Minimum Pressure: 53 PSI
Maximum Pressure: 57 PSI
Outlet Outside Diameter: 9.49 mm
Pump Type: Electric
Fuel Type: Gas
In Tank or External: In Tank
Wire Harness Included: No
Fuel Tank Pressure Sensor Included: No
Lock Ring Included: No
Outlet Type: Quick Connect
Inlet Type: Strainer
Gasket Or Seal Included: Yes
Fuel Sending Unit Included: Yes
Strainer Included: Yes
Product Features Complete Assembly: No modifications or assembly required Carbon Brush and Commutator: More than twice the service life compared to copper Flourine Rubber Seals: Resistant to high temperature, fuel, and solvents SAE J2044 Compliant: Improved mounting security, minimized installation error
Reference Numbers
150120-A
2L1Z9H307BA
2L1Z9H307BB
2L1Z9H307BF
323-01671
4010369
E2360M
FG0860
P76022M
SP2360M
USEP2360M
